Mechanical
Application QFN / QFP / LGA / BGA
Height 4.5mm / 5.2mm (Test / Rest)
Working Spring Force 35gf@0.70mmTemperature -40~120℃
Tip (device / PCB) Crown / Cone
Electrical
Contact resistance < 80 mΩ
Current Carrying Capability 2A Continuous
Insertions
Cycle life > 200K
BOM (Material VS Plating)
Plunger-top : Pd Alloy
Plunger-bottom : BeCu / Au plated
Spring : Music Wire / Au plated
