Mechanical
Application BGA
Height 2.9mm / 3.3mm (Test / Rest)
Working Spring Force 31gf@0.4mm
Temperature -50~155℃
Tip (device side / PCB side) Crown / Cone
Height 2.9mm / 3.3mm (Test / Rest)
Working Spring Force 31gf@0.4mm
Temperature -50~155℃
Tip (device side / PCB side) Crown / Cone
Electrical
Contact resistance < 80 mΩ
Current carrying capability 2A continuous
Insertions
Cycle life > 300K
BOM (Material VS Plating)
Plunger-top : Pd Alloy
Plunger-bottom : BeCu / Au plated
Barrel : PBT / Au plated
Spring : SWP / Au plated
