Mechanical
Application QFN / BGA
Height 2.1mm / 2.4mm (Test / Rest)
Pitch Range (MIN.)0.35mm
Working Spring Force 25gf@0.3mm
Temperature -50~125℃
Tip (device side / PCB side) Crown / Cone
Height 2.1mm / 2.4mm (Test / Rest)
Pitch Range (MIN.)0.35mm
Working Spring Force 25gf@0.3mm
Temperature -50~125℃
Tip (device side / PCB side) Crown / Cone
Electrical
Current capacity 1.5A Continuous
Self-inductance 0.48nH
Parasitic capacitance 0.27pF
DC Resistance < 60 mΩ (Average)
Bandwidth @ -1dB 20GHz
Insertions
Cycle life > 300K
BOM (Material VS Plating)
Plunger-top : Pd Alloy
Barrel : PBT / Au plated
Spring : SWP-U / Au plated
Bottom : BeCu / Au plated
