Mechanical
Application QFN / QFP / LGA
Height 2.9mm / 3.3mm (Test / Rest)
Working Spring Force 24gf@0.4mm
Temperature -55~155℃
Tip (device side / PCB side) Kelvin / Cone
Height 2.9mm / 3.3mm (Test / Rest)
Working Spring Force 24gf@0.4mm
Temperature -55~155℃
Tip (device side / PCB side) Kelvin / Cone
Electrical
Contact resistance < 70 mΩ
Current Carrying Capability 2A Continuous
Insertions
Cycle life > 300K
BOM (Material VS Plating)
Plunger-top : Pd Alloy
Plunger-bottom : BeCu / Au plated
Barrel : PBT / Au plated
Spring : NAS604 / Au plated
