Mechanical
Application QFN / QFP / LGA / BGA
Height 2.8mm / 3.2mm (Test / Rest)
Working Spring Force 30.8gf@0.40mm
Temperature -40~125℃Working Spring Force 30.8gf@0.40mm
Tip (device / PCB) Crown / Cone
Electrical
Contact resistance < 50 mΩ
Current Carrying Capability 3A Continuous
Insertions
Cycle life > 300K
BOM (Material VS Plating)
Plunger-top : Pd Alloy
Plunger-bttom : BeCu / Au plated
Barrel : PBT / Au plated
Spring : SWP / Au plated
